Which Chipsets Work With Intel's Core i9-9900 CPU?

Find out which retail desktop chipsets are compatible with Intel's 9th generation Core i9 9900 processors.

9900 Chipsets Timur Garifov / Unsplash

Last Updated: June 23, 2022

Written by Kevin Jones

In addition to discussing the chipsets that are compatible with Intel's Core i9 9900 processor, this article will discuss Recommended Motherboards below.

Check another CPU:
Intel Core i9-9900 Intel Core i9-9900 Check Price on Amazon Amazon Affiliate Link

Which Chipsets Are Compatible With the Core i9-9900 Processor?

Section Link

For Intel's 9th generation Core i9 9900 processor, you'll need a motherboard with an LGA 1151 socket and 300-series chipset.

Motherboards for Intel processors are made with chipsets provided by Intel. Each chipset offers a unique set of capabilities. However, motherboards must explicitly support features and capabilities for you to use them. Verify that a motherboard supports the features and capabilities you desire.

The lack of a "K" suffix in the model name 9900 means it doesn't support overclocking. Because of this, there is no need for you to use the top of the line Z390 or Z370 chipsets which support overclocking. Instead, you can use a motherboard with Intel's other 300-series desktop chipsets listed below.

For compatiblity with Intel's 11th generation Core processors, you can use any of the 300-series chipsets: Z390, Z370, H370, B365, B360, H310. These are roughly sorted from most to least functionality.

The Q370 chipset is also compatible, but is intended for business use cases; its availability in stand-alone motherboards is limited.

Intel 500 Series Desktop Chipsets
Z390Z370H370B365B360H310Q370
Recommended Usage For Enthusiast Gamer PCs For Enthusiast Gamer PCs For General Home and Gaming PCs For Budget PCs For Budget PCs For Barebones PCs For Nicer Business PCs
Motherboard Availability Limited
Launch Date Q4 2018 Q4 2017 Q2 2018 Q4 2018 Q2 2018 Q2 2018 Q2 2018
CPU Overclocking Yes Yes No No No No No
Memory Overclocking Yes Yes No No No No No
PCIe 3.0 Slots via Processor One x16
or Two x8
or One x8 + Two x4
One x16
or Two x8
or One x8 + Two x4
One x16 One x16 One x16 One x16 One x16
or Two x8 or One x8 + Two x4
PCIe 3.0 Lanes via Chipset 24 24 20 20 12 None 24
PCIe 2.0 Lanes via Chipset None None None None None 6 None
Integrated Wireless Wireless-AC MAC None Wireless-AC MAC None Wireless-AC MAC Wireless-AC MAC Wireless-AC MAC
USB 3.2 Gen 2x1 (10 Gbps) Up to 6 None Up to 4 None Up to 4 None Up to 6
USB 3.2 Gen 1x1 (5 Gbps) Up to 10 Up to 10 Up to 8 8 Up to 6 4 Up to 10
USB 2.0 Ports 14 Up to 14 14 Up to 14 12 10 14
SATA 3.0 Ports 6 6 6 6 6 4 6
PCIe RAID 0, 1, 5 0, 1, 5 0, 1, 5 0, 1, 5 None None 0, 1, 5
SATA RAID 0, 1, 5, 10 0, 1, 5, 10 0, 1, 5, 10 0, 1, 5, 10 None None 0, 1, 5, 10
Section Link

Best Feature Motherboard: MSI Z390-a PRO

  • Our recommended feature-rich motherboard to pair with the Core i9-9900 is MSI's Z390-A PRO motherboard: MSI Z390-A PRO MSI Z390-A PRO Check Price on Amazon Amazon Affiliate Link
    • One NVMe M.2 slots at PCIe 3.0 x4 speeds.
    • Up to 6 SATA 6 Gb/s ports (When using an M.2 SATA device, the SATA2 port will be unavailable).
    • The two USB 3.1 Gen2 ports offer 10 Gbps USB speeds.
    • One 1 Gb Ethernet port is faster than most Internet speeds.
    • This board includes various headers for accessories, including a 4-pin Water Pump connector.
    • Check the latest price of the MSI Z390-A PRO on Amazon (affiliate link).

Best Value Motherboard: ASUS Prime Z390-P

  • Our recommended value motherboard to pair with the Core i9-9900 is ASUS's Prime Z390-P motherboard: ASUS Prime Z390-P ASUS Prime Z390-P Check Price on Amazon Amazon Affiliate Link
    • Two NVMe M.2 x4 slots at PCIe 3.0 speeds.
    • Up to 4 SATA 3.0 ports, depending on M.2 configuration.
    • USB 3.2 Gen 2x1 offers 10 Gbps USB speeds.
    • One 1 Gb Ethernet port is faster than most Internet speeds.
    • This board includes various headers and ports for accessories, including a liquid pump header and extra x1 PCIe slots.
    • Check the latest price of the ASUS Prime Z390-P on Amazon (affiliate link).

Learn More About the Intel Core i9-9900

Section Link

You can find detailed 9900 specifications on Intel's site.

Intel Core i9-9900 Intel Core i9-9900 Check Price on Amazon Amazon Affiliate Link
