Which Chipsets Work With AMD's Ryzen 7 1700 CPU?

Find out which retail desktop chipsets are compatible with AMD's Zen-based Ryzen 7 1700 processors, along with our recommended motherboards to pair with this CPU.

Which Chipsets Work With AMD's Ryzen 7 1700 CPU? Kevin Jones / TechReviewer

Last Updated: May 26, 2023

Written by Kevin Jones

When building a powerful and efficient PC using AMD's Ryzen 7 1700 processor, selecting the right motherboard is crucial. With our experience as PC builders, we understand the importance of finding a compatible motherboard for a CPU. In addition, we understand the necessity of choosing one that offers the desired features. In this article, we will discuss the chipsets compatible with AMD's Ryzen 7 1700. Our analysis and breakdown will help you make an informed decision to optimize your system's performance.

Furthermore, we researched the available motherboard options and have curated a list of our Recommended Motherboards for the Ryzen 7 1700 below. This will simplify the decision-making process for you, making it easier to choose the right motherboard for your needs. Keep in mind that OEM-only chipsets that are not available on retail motherboards are outside the scope of this article.

Check another CPU:
Best B450 Motherboard
Photo of the GIGABYTE B450 AORUS PRO Wi-Fi GIGABYTE B450 AORUS PRO Wi-Fi Check Price on Amazon Amazon Affiliate Link

Which Chipsets Are Compatible With the Ryzen 7 1700 Processor?

Section Link

For AMD's Zen-based Ryzen 7 1700 processor, you'll need a motherboard with an AM4 socket and a compatible chipset.

Motherboards for AMD processors are made with chipsets provided by AMD. Each chipset offers a unique set of capabilities. However, motherboards must explicitly support features and capabilities for you to use them. Verify that a motherboard supports the features and capabilities you desire.

Ryzen 1000-series CPUs, which includes the Ryzen 7 1700, are compatible with all 300 and 400-series consumer chipsets. Supported chipsets include the X470, B450, X370, B350, and A320.

The X470 and B450 are our recommended chipsets for the Ryzen 7 1700 CPU, as they provide the most functionality among compatible chipsets.

Note that the Ryzen 7 1700 CPU only supports PCIe 3.0.

400-Series Chipsets

Featured X470 Motherboards › Amazon Affiliate Links Photo of the MSI Performance Gaming AMD X470 Ryzen 2ND and 3rd Gen AM4 DDR4 DVI HDMI Onboard Graphics CFX ATX Motherboard (X470 GAMING PLUS Max) MSI Performance Gaming AMD X470 Ryzen 2ND and 3rd Gen AM4 DDR4 DVI HDMI Onboard Graphics CFX ATX Motherboard (X470 GAMING PLUS Max) Check Price on Amazon
AMD 400-Series Desktop Chipsets
X470 B450
Release Date March 2018 March 2018
CPU Overclocking Yes Yes

PCIe Slots via Processor See Exceptions: MAX, 4.0

One x16 + One x4 or Two x8 + One x4 at PCIe 3.0 speeds

One x16 + One x4 at PCIe 3.0 speeds

PCIe Lanes via Chipset See Exceptions: MAX

 Up to 8 lanes at PCIe 2.0 speeds Up to 6 lanes at PCIe 2.0 speeds
USB 3.2 Gen 2x1 (10 Gbps) Up to 2 Up to 2
Total USB Up to 18 Up to 14
SATA 3.0 Ports Up to 10 Up to 6
RAID 0, 1, 10 0, 1, 10

MAX The maximum supported PCI-Express version for the Ryzen 7 1700 CPU is PCIe 3.0.

4.0 PCIe 4.0 speeds may be supported for CPU lanes on some motherboards, with a BIOS update and CPU that supports PCIe 4.0.

300-Series Chipsets

The A320 chipset does not support overclocking Zen-based CPUs.

AMD 300-Series Desktop Chipsets
X370 B350 A320
Release Date February 2017 February 2017 February 2017
CPU Overclocking Yes Yes Pre-Zen CPUs Only

PCIe Slots via Processor See Exceptions: MAX

One x16 + One x4 or Two x8 + One x4 at PCIe 3.0 speeds

One x16 + One x4 at PCIe 3.0 speeds

One x16 + One x4 at PCIe 3.0 speeds

PCIe Lanes via Chipset See Exceptions: MAX

 Up to 8 lanes at PCIe 2.0 speeds Up to 6 lanes at PCIe 2.0 speeds Up to 4 lanes at PCIe 2.0 speeds
USB 3.2 Gen 2x1 (10 Gbps) Up to 2 Up to 2 Up to 1
Total USB Up to 18 Up to 14 Up to 13
SATA 3.0 Ports Up to 10 Up to 6 Up to 6
RAID 0, 1, 10 0, 1, 10 0, 1, 10

MAX The maximum supported PCI-Express version for the Ryzen 7 1700 CPU is PCIe 3.0.

Section Link

Best Motherboard: GIGABYTE B450 AORUS PRO Wi-Fi

  • Our recommended B450 motherboard to pair with the Ryzen 7 1700:

  • GIGABYTE B450 AORUS PRO Wi-Fi TechReviewer

  • Through our analysis and research, we found that the GIGABYTE B450 AORUS PRO Wi-Fi motherboard offers a great range of features for this generation of CPUs. The motherboard's support for up to 128 GB of DDR4 memory ensures smooth multitasking and responsive performance at a lower price than DDR5. The smaller microATX form factor is backward compatible with any full-size ATX case.

  • We found that the GIGABYTE B450 AORUS PRO Wi-Fi motherboard offers a 1 Gbps Ethernet port enables speedy internet or file transfers.

  • We also appreciated the storage options with the GIGABYTE B450 AORUS PRO Wi-Fi. It features two NVMe M.2 slots at PCIe 3.0 speeds, allowing for quick access to your games, applications, and media. Its USB 3.2 Gen 2 slots also offers 10 Gbps USB speeds.

  • Overall, we concluded that the GIGABYTE B450 AORUS PRO Wi-Fi motherboard strikes a balance between performance and functionality, offering a great gaming experience. Photo of the GIGABYTE B450 AORUS PRO Wi-Fi GIGABYTE B450 AORUS PRO Wi-Fi Check Price on Amazon Amazon Affiliate Link
