This article will discuss choosing a motherboard for AMD's Ryzen 7 7700 processor. Check out my Recommended Motherboards below, along with compatible CPU coolers and memory. OEM-only chipsets that are not available on retail motherboards are outside the scope of this article.
For AMD's Zen 4-based Ryzen 7 7700 processor, you'll need a motherboard with an AM5 socket and a compatible chipset.
Motherboards for AMD processors are made with chipsets provided by AMD. Each chipset offers a unique set of capabilities. However, motherboards must explicitly support features and capabilities for you to use them. Verify that a motherboard supports the features and capabilities you desire.
Ryzen 7000-series CPUs, which includes the Ryzen 7 7700, are compatible with the 600-series consumer chipsets. Supported chipsets include the X670E, X670, B650E, and B650.
The X670E is our recommended motherboard chipset for the Ryzen 7 7700 CPU, as it provides the most functionality and full support for PCIe 5.0. The Ryzen 7 7700 CPU also supports PCIe 5.0.
For a detailed comparison of these chipsets and PCIe speeds, check out my article Which Chipsets Work With AMD's Ryzen 7 7700 CPU?.
- Find Zen 4 X670E Motherboards on Amazon (affiliate link).
- Find Zen 4 X670 Motherboards on Amazon (affiliate link).
- Find Zen 4 B650E Motherboards on Amazon (affiliate link).
- Find Zen 4 B650 Motherboards on Amazon (affiliate link).
Check out my Recommended Motherboards for the 7700 below.
In addition to selecting a motherboard with a socket type and chipset compatible with the 7700, here are a few other things to consider when picking a motherboard. Some of these considerations will help determine the best chipset to use.
Video Output Port
All Ryzen 7000 CPUs have integrated graphics support. You will need to make sure that your motherboard also has a video output port (e.g., HDMI) if you want to use the integrated graphics.
The integraded graphics on the Ryzen 7000 CPUs have 2 cores, 2200 MHz graphics frequency, and a 400 MHz GPU base frequency. This is good for basic tasks, but not for most games or other GPU-intense programs.
Storage: M.2 Slots and SATA Ports
NVMe M.2 cards are the latest and fastest form of SSD storage. However, you need to ensure that your motherboard includes enough slots.
NVMe Support: The X670E, X670, and B650E chipsets support up to one x4 NVMe at PCIe 5.0 speeds (via CPU) and up to one x4 NVMe at PCIe 5.0 speeds (via chipset). The B650 chipset supports one x4 NVMe at PCIe 4.0 speeds (via CPU).
SATA Support: The X670E and X670 chipsets support up to 8 SATA ports, while the B650E and B650 chipsets support up to 4 SATA ports.
Learn more about storage types in my article Storage Type Comparison: M.2, U.2, NVMe, SATA, SSDs, HDDs.
Make sure that the motherboard provides enough USB ports at your desired speeds.
The X670E and X670 chipsets support up to 12 superspeed (10Gbps) USB ports and 2 superspeed (20Gbps) USB ports. The B650E and B650 chipsets, in comparison, only support up to 6 superspeed (10Gbps) USB ports and 1 superspeed (20Gbps) USB port. Each motherboard is different, so the amount and speed of USB ports may vary.
The devices that are likely to need the high bandwidth rates will typically be limited to storage devices and high-resolution video devices.
Make sure that the motherboard has your desired audio outputs.
For example, if you have a surround sound system, ensure that it comes with rear and center speaker ports.
If your audio equipment requires an optical input, consider getting a motherboard with this port.
Alternatively, you can purchase a separate PCIe or USB sound card to add additional port types such as optical or RCA.
Motherboards typically come in one of three form factors. ATX is the most common motherboard form factor for a desktop PC.
You might also consider Mini-ITX or MicroATX form factors to build a mini-PC. Keep in mind that these smaller form factors typically have fewer PCIe card slots, fewer RAM slots, and can not support as many storage devices.
These smaller Mini-ITX and MicroATX motherboard form factors are backward compatible with standard ATX cases. They use a subset of the ATX mounting holes. You can also use Mini-ITX motherboards in MicroATX cases.
You will need a computer case compatible with your motherboard form factor.
PCIe Expansion Slots
The X670E and B650E chipsets allow for multiple graphics cards in the dual x8 configuration at PCIe 5.0 speeds, while the X670 and B650 only run at PCIe 4.0 speeds for both a single x16 slot or dual x8 slots.
Best Feature Motherboard
- Our recommended feature-rich motherboard to pair with the Ryzen 7 7700:
- PCIe 5.0 support
- X670E chipset
- One 2.5 Gb Ethernet port
- Four NVMe M.2 slots and Four SATA 6 Gb/s ports
- Wi-Fi 6E provides fast connections to a Wi-Fi router.
- Bluetooth 5.2 support
- USB 3.2 Gen 2x2 offers 20 Gbps USB speeds and 12 USB 3.2 Gen 2 ports
- Check the latest price of the ASUS ROG Strix X670E-E Gaming Motherboard on Amazon (affiliate link).
- Our recommended runner-up motherboard to pair with the Ryzen 7 7700:
Best Value Motherboard
- Our recommended value motherboard to pair with the Ryzen 7 7700:
- PCIe 4.0 for graphics
- X670 chipset
- One 2.5 Gb Ethernet port
- Four NVMe M.2 slots and Four SATA 6 Gb/s ports. PCIe 5.0 speeds for one of the M.2 slots
- Bluetooth 5.2 support
- USB 3.2 Gen 2x2 offers 20 Gbps USB speeds
- Check the latest price of the GIGABYTE X670 AORUS Elite AX Motherboard on Amazon (affiliate link).
