Which Chipsets Work With AMD's Ryzen 5 Pro 3600 CPU?

Find out which retail desktop chipsets are compatible with AMD's Zen 2-based Ryzen 5 Pro 3600 processors, along with our recommended motherboards to pair with this CPU.

Which Chipsets Work With AMD's Ryzen 5 Pro 3600 CPU? Brandon Jones / TechReviewer

Last Updated: March 24, 2025

Written by Brandon Jones

Best Feature Motherboard
MSI MAG X570 TOMAHAWK WIFI
Best Value Motherboard
ASUS AM4 TUF Gaming X570-Plus (Wi-Fi)
Check another CPU:

Which Chipsets Are Compatible With the Ryzen 5 Pro 3600 Processor?

Section Link

For AMD's Zen 2-based Ryzen 5 Pro 3600 processor, you'll need a motherboard with an AM4 socket and a compatible chipset.

Motherboards for AMD processors are made with chipsets provided by AMD. Each chipset offers a unique set of capabilities. However, motherboards must explicitly support features and capabilities for you to use them. Verify that a motherboard supports the features and capabilities you desire.

Ryzen 3000-series CPUs without Radeon Graphics, which includes the Ryzen 5 Pro 3600, are compatible with all 400 and 500-series consumer chipsets. Supported chipsets include the X570, B550, A520, X470, and B450.

The older X370 and B350 300-series chipsets are generally not compatible, out of the box, with Ryzen 3000-series CPUs without Radeon Graphics. However, the 300-series chipsets may be supported by some motherboard manufacturers, when using a specific compatible BIOS. This CPU is not compatible with the A320 300-series chipset.

The X570 is our recommended chipset for the Ryzen 5 Pro 3600 CPU, as it provides the most functionality and full support for PCIe 4.0. The Ryzen 5 Pro 3600 CPU also supports PCIe 4.0.

Only the X570 chipset provides PCIe 4.0 lanes via the chipset.

When using motherboards with the B550 chipset, you still have PCIe 4.0 lanes from the CPU for PCI-Express slots; however, all PCIe or M.2 slots connected via these chipsets will run at PCIe 3.0 speeds.

500-Series Chipsets

AMD 500-Series Desktop Chipsets
X570 B550 A520
Release Date July 2019 June 2020 August 2020
CPU Overclocking Yes Yes No

PCIe Slots via Processor See Exceptions: MAX, 1, 2, 3

One x16 + One x4 at PCIe 4.0 speeds

or Two x8 + One x4 at PCIe 4.0 speeds

One x16 + One x4 at PCIe 4.0 speeds

or Two x8 + One x4 at PCIe 4.0 speeds

One x16 + One x4 at PCIe 3.0 speeds

PCIe Lanes via Chipset See Exceptions: MAX

 Up to 16 lanes at PCIe 4.0 speeds Up to 10 lanes at PCIe 3.0 speeds Up to 6 lanes at PCIe 3.0 speeds
USB 3.2 Gen 2x1 (10 Gbps) Up to 12 Up to 6 Up to 5
Total USB Up to 16 Up to 14 Up to 13
SATA 3.0 Ports Up to 14 Up to 8 Up to 6
RAID 0, 1, 10 0, 1, 10 0, 1, 10

MAX The maximum supported PCI-Express version for the Ryzen 5 Pro 3600 CPU is PCIe 4.0.

1 PCIe 4.0 requires a Zen 2 or newer processor.

2 "G" CPUs: One x8 + One x4 at PCIe 3.0 speeds.

3 A-Series CPUs: One x8 + One x2 at PCIe 3.0 speeds.

400-Series Chipsets

When using motherboards with a 400-series chipset, you will be limited to PCIe 3.0 lanes from the CPU for PCI-Express slots. All PCIe or M.2 slots connected via the 400-series chipsets will run at PCIe 2.0 speeds.

Featured X470 Motherboards › MSI AMD X470 Pro Carbon Gaming ATX DDR4-SDRAM Motherboard
AMD 400-Series Desktop Chipsets
X470 B450
Release Date March 2018 March 2018
CPU Overclocking Yes Yes

PCIe Slots via Processor See Exceptions: MAX, 4.0

One x16 + One x4 or Two x8 + One x4 at PCIe 3.0 speeds

One x16 + One x4 at PCIe 3.0 speeds

PCIe Lanes via Chipset See Exceptions: MAX

 Up to 8 lanes at PCIe 2.0 speeds Up to 6 lanes at PCIe 2.0 speeds
USB 3.2 Gen 2x1 (10 Gbps) Up to 2 Up to 2
Total USB Up to 18 Up to 14
SATA 3.0 Ports Up to 10 Up to 6
RAID 0, 1, 10 0, 1, 10

MAX The maximum supported PCI-Express version for the Ryzen 5 Pro 3600 CPU is PCIe 4.0.

4.0 PCIe 4.0 speeds may be supported for CPU lanes on some motherboards, with a BIOS update and CPU that supports PCIe 4.0.

Important considerations regarding this CPU:

AMD's Ryzen Pro CPUs are intended for the business market. They are generally found in pre-built systems and do not support overclocking.

The Ryzen 5 Pro 3600 CPU isn't available in a boxed version. However, you may be able to purchase it in a tray version or as part of a pre-built computer.

Tray versions are sold in bulk, without retail-box packaging. These CPUs are then sometimes sold again, individually.

Section Link

Best Value Motherboard: ASUS TUF Gaming X570-Plus Wi-Fi

  • Our recommended value motherboard to pair with the Ryzen 5 Pro 3600 is the ASUS TUF Gaming X570-Plus (Wi-Fi):

  • ASUS TUF Gaming X570-Plus Wi-Fi
    Max PCIe Version 4.0
    Max RAM: 128 GB DDR4
    NVMe slots: 2
    Ethernet: 1 Gbps

  • Through our analysis and research, we found that the ASUS TUF Gaming X570-Plus Wi-Fi motherboard offers an impressive range of features designed to enhance your gaming experience. With PCIe 4.0 support, you can enjoy fast data transfer rates, giving you a competitive edge. The motherboard's support for up to 128 GB of DDR4 memory ensures smooth multitasking and responsive performance at a lower price than DDR5. This motherboard has the X570 chipset.

  • We found that the ASUS TUF Gaming X570-Plus Wi-Fi motherboard offered superior connectivity as well. Its 1 Gbps Ethernet port enables speedy file transfers, surpassing typical home internet speeds. 802.11ac Wi-Fi provides fast wireless connections, making online gaming and streaming seamless. Plus, Bluetooth 5.2 support allows convenient music streaming to Bluetooth headphones.

  • We also appreciated the plentiful storage options with the ASUS TUF Gaming X570-Plus Wi-Fi. It features two x4 NVMe M.2 slots (PCIe 5.0 speeds for one of the M.2 slots) and Four SATA 6 Gb/s ports, allowing for efficient storage and quick access to your games, applications, and media. Its USB 3.2 Gen 2 slots also offers 10 Gbps USB speeds.

  • Overall, we concluded that the ASUS TUF Gaming X570-Plus Wi-Fi motherboard strikes a balance between performance and functionality, offering an exceptional gaming experience. With its advanced features and versatile connectivity options, this motherboard is a reliable choice for gamers looking to elevate their gameplay. ASUS AM4 TUF Gaming X570-Plus (Wi-Fi)

Best Feature Motherboard: MSI MAG X570 TOMAHAWK WIFI

  • Our recommended feature-rich motherboard to pair with the Ryzen 5 Pro 3600:

  • MSI MAG X570 TOMAHAWK WIFI
    Max PCIe Version 4.0
    Max RAM: 128 GB DDR4
    NVMe slots: 2
    Ethernet: 2.5 Gbps

  • Through our analysis and research, we found that the MSI MAG X570 TOMAHAWK WIFI motherboard offers an impressive range of features designed to enhance your gaming experience. With PCIe 4.0 support, you can enjoy fast data transfer rates, giving you a competitive edge. The motherboard's support for up to 128 GB of DDR4 memory ensures smooth multitasking and responsive performance at a lower price than DDR5. This motherboard has the X570 chipset.

  • We found that the MSI MAG X570 TOMAHAWK WIFI motherboard offered superior connectivity as well. Its 2.5 Gbps Ethernet port enables speedy file transfers, surpassing typical home internet speeds. Wi-Fi 6 provides fast wireless connections, making online gaming and streaming seamless. Plus, Bluetooth 5.2 support allows convenient music streaming to Bluetooth headphones.

  • We also appreciated the plentiful storage options with the MSI MAG X570 TOMAHAWK WIFI. It features two x4 NVMe M.2 slots (PCIe 5.0 speeds for one of the M.2 slots) and Four SATA 6 Gb/s ports, allowing for efficient storage and quick access to your games, applications, and media. Its USB 3.2 Gen 2 slots also offers 10 Gbps USB speeds.

  • Overall, we concluded that the MSI MAG X570 TOMAHAWK WIFI motherboard strikes a balance between performance and functionality, offering an exceptional gaming experience. With its advanced features and versatile connectivity options, this motherboard is a reliable choice for gamers looking to elevate their gameplay. MSI MAG X570 TOMAHAWK WIFI
