In this article, I go over the requirements you need to know when looking for the correct motherboard for your 13th gen Intel CPU, along with other considerations when choosing a motherboard.
To help you decide further, I list my Recommended 13th Gen Motherboards and CPUs
below.
Motherboard Requirements for Intel's 13th Generation Core CPUs
Motherboards for Intel processors are made with chipsets provided by Intel. Each chipset offers a unique set of capabilities. However, motherboards must explicitly support features and capabilities for you to use them. Verify that a motherboard supports the features and capabilities you desire.
For 13th Gen Intel Core processors, you'll need a motherboard with an LGA 1700 socket and a 700-series or 600-series chipset. However, 600-series chipsets were designed for the 12th generations Core processors and may limit the capabilities of your system.
You will need a motherboard with overclocking support to overclock 13th Gen CPUs. Motherboards with the Z790 and Z690 chipsets typically support CPU overclocking. Otherwise, you can use a motherboard with Intel's other 700-series or 600-series desktop chipsets (e.g., H770, B760, H670, B660, H610).
The W680 and Q670 chipsets are intended for workstation and business use cases; their availability in stand-alone motherboards is limited.
To use 13th Gen Intel Core CPUs with the 600-series chipsets, you'll need an updated BIOS. You either need to purchase one with an updated BIOS, perform the update with a 12th Gen CPU installed, or use the USB BIOS Flashback feature (if available).
Products that ship with a compatible BIOS are typically marked as "Ready" for 13th Gen Intel processors.
for a specific 13th Gen Core CPU:
| Z790 | H770 | B760 | Z690 | H670 | B660 | H610 | W680 | Q670 | |
|---|---|---|---|---|---|---|---|---|---|
| Recommended Usage | For Enthusiast Gamer PCs | For General Home and Gaming PCs | For Budget PCs | For Enthusiast Gamer PCs | For General Home and Gaming PCs | For Budget PCs | For Barebones PCs |
For High-End Creative/ | For Nicer Business PCs |
| Motherboard Availability | Limited | Limited | |||||||
| Launch Date | Q4 2022 | Q1 2023 | Q1 2023 | Q4 2021 | Q1 2022 | Q1 2022 | Q1 2022 | Q1 2022 | Q1 2022 |
|
CPU Overclocking See Exceptions: MOTHERBOARD | Yes | No | No | Yes | Yes | Yes | No | Yes | No |
| Memory Overclocking | Yes | Yes | Yes | Yes | Yes | Yes | No | Yes | No |
| PCIe 5.0 Slots via Processor | One x16 or Two x8 | One x16 or Two x8 | One x16 | One x16 or Two x8 | One x16 or Two x8 | One x16 | One x16 | One x16 or Two x8 | One x16 or Two x8 |
| PCIe 4.0 Slots via Processor | One x8 | One x4 | One x4 | One x4 | One x4 | One x4 | None | One x4 | One x4 |
| PCIe 4.0 Lanes via Chipset | Up to 20 | Up to 16 | Up to 10 | Up to 12 | Up to 12 | Up to 6 | None | Up to 12 | Up to 12 |
| PCIe 3.0 Lanes via Chipset | Up to 8 | Up to 8 | Up to 4 | Up to 16 | Up to 12 | Up to 8 | 8 | Up to 16 | Up to 12 |
| Memory Channels | 2 | 2 | 2 | 2 | 2 | 2 | 1 | 2 | 2 |
| Integrated Wireless | Wi-Fi 6E AX211 (Gig+) | Wi-Fi 6E AX211 (Gig+) | Wi-Fi 6E AX211 (Gig+) | Wi-Fi 6E AX211 (Gig+) | Wi-Fi 6E AX211 (Gig+) | Wi-Fi 6E AX211 (Gig+) | Wi-Fi 6E AX211 (Gig+) | Wi-Fi 6E AX211 (Gig+) | Wi-Fi 6E AX211 (Gig+) |
| DMI 4.0 Lanes | 8 | 8 | 4 | 8 | 8 | 4 | 4 | 8 | 8 |
| USB 3.2 Gen 2x2 (20 Gbps) | Up to 5 | Up to 2 | Up to 2 | Up to 4 | Up to 2 | Up to 2 | None | Up to 4 | Up to 4 |
| USB 3.2 Gen 2x1 (10 Gbps) | Up to 10 | Up to 4 | Up to 4 | Up to 10 | Up to 4 | Up to 4 | Up to 2 | Up to 10 | Up to 8 |
| USB 3.2 Gen 1x1 (5 Gbps) | Up to 10 | Up to 8 | Up to 6 | Up to 10 | Up to 8 | Up to 6 | Up to 4 | Up to 10 | Up to 10 |
| USB 2.0 Ports | 14 | 14 | 12 | 14 | 14 | 12 | 10 | 14 | 14 |
| Wi-Fi 6E | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| SATA 3.0 Ports | Up to 8 | Up to 8 | Up to 4 | Up to 8 | Up to 8 | Up to 4 | Up to 4 | Up to 8 | Up to 8 |
| PCIe RAID | 0, 10, 15 | 0, 10, 15 | None | 0, 1, 5, 10 | 0, 1, 5, 10 | None | None | 0, 1, 5, 10 | 0, 1, 5, 10 |
| SATA RAID | 0, 10, 15 | 0, 10, 15 | 0, 10, 15 | 0, 1, 5, 10 | 0, 1, 5, 10 | 0, 1, 5, 10 | None | 0, 1, 5, 10 | 0, 1, 5, 10 |
MOTHERBOARD The motherboard must support overclocking to use overclocking capabilities. Motherboards with Z-prefixed chipsets more commonly support overclocking.
Find Z790 Chipset Motherboards on Amazon (affiliate link).
Find H770 Chipset Motherboards on Amazon (affiliate link).
Find B760 Chipset Motherboards on Amazon (affiliate link).
Find Z690 Chipset Motherboards on Amazon (affiliate link).
Find H670 Chipset Motherboards on Amazon (affiliate link).
Find B660 Chipset Motherboards on Amazon (affiliate link).
Find H610 Chipset Motherboards on Amazon (affiliate link).
DDR4 or DDR5 Memory
Because DDR4 and DDR5 are not backward compatible, you must decide which one you want to go with before selecting a motherboard.
DDR5 memory is currently more expensive than DDR4.
However, it offers up to double the stock data rates of DDR4. Overclockers could push this limit even further.
Additionally, DDR5 supports higher-capacity DIMMs (256 GB vs. 64 GB).
DDR5 may experience slower timings at initial release but should be much better than DDR4 as the technology matures. However, keep in mind that the timings scale inversely with the clock rate (frequency). The timing values are in units of clock cycles, but more cycles are happening per second with DDR5. For example, DDR3-2133 CL10 has nearly the same latency as DDR5-8400 CL40. So don't let the CL40 latency of DDR5 scare you away; the number just looks bigger!
| DDR4 | DDR5 | |
|---|---|---|
| Max UDIMM (Unbuffered) Capacity | 32 GB | 128 GB |
| Bandwidth | 12800–25600 MB/s | 38400–57600 MB/s |
| Transfer Rate | 1600–3200 MT/s | 4800–7200 MT/s |
| Base Frequency | 800–1600 MHz | 2400–3600 MHz |
| Effective Frequency | 1600–3200 MHz | 4800–7200 MHz |
| Voltage | 1.2 V | 1.1 V |
| On-die ECC | No | Yes |
Corsair DOMINATOR PLATINUM RGB DDR5 32 GB (2 x 16 GB) 5600 MHz RAM
Check Price on Amazon
Amazon Affiliate Link
Other Considerations When Choosing a 13th Gen Motherboard
In addition to selecting a motherboard with an LGA 1700 socket type and compatible chipset, here are a few other things to consider when picking a motherboard. Some of these considerations will help determine the best chipset to use.
Memory Overclocking
To be able to overclock DDR memory, such as via an XMP profile, your motherboard chipset needs to support memory overclocking.
Video Output Port
An "F" in the CPU's model name indicates that the CPU does not have integrated graphics support and requires a separate graphics card. Because it doesn't have integrated graphics support, you won't need a motherboard with a video output port (e.g., HDMI).
The lack of an "F" in the model name indicates that the CPU has integrated graphics support. You will need to make sure that your motherboard also has a video output port (e.g., HDMI) if you want to use the integrated graphics.
Even if you primarily connect your monitors to a graphics card, integrated graphics can be beneficial when troubleshooting and fixing graphics card problems.
ASUS ROG Strix Z790-E Gaming WiFi 6E
Check Price on Amazon
Amazon Affiliate Link
Storage: M.2 Slots and SATA Ports
NVMe M.2 cards are the latest and fastest form of SSD storage. However, you need to ensure that your motherboard includes enough slots.
The Z790, H770, Z690, and H670 chipsets support the most PCIe 4.0 lanes, which means that motherboards with these chipsets are likely to have the most x4 NVMe M.2 slots available.
Learn more about storage types in my article Storage Type Comparison: M.2, U.2, NVMe, SATA, SSDs, HDDs.
Connectivity
USB
Make sure that the motherboard provides enough USB ports at your desired speeds. The Z690 and Z790 can support the most USB ports at USB 3.2 2x2 (20 Gbps), USB 3.2 2x1 (10 Gbps), and USB 3.2 1x1 (5 Gbps) speeds.
The devices that are likely to need the high bandwidth rates will typically be limited to storage devices and high-resolution video devices.
Audio
Make sure that the motherboard has your desired audio outputs.
For example, if you have a surround sound system, ensure that it comes with rear and center speaker ports.
If your audio equipment requires an optical input, consider getting a motherboard with this port.
Alternatively, you can purchase a separate PCIe or USB sound card to add additional port types such as optical or RCA.
Form Factor
Motherboards typically come in one of three form factors. ATX is the most common motherboard form factor for a desktop PC.
You might also consider Mini-ITX or MicroATX form factors to build a mini-PC. Keep in mind that these smaller form factors typically have fewer PCIe card slots, fewer RAM slots, and can not support as many storage devices.
These smaller Mini-ITX and MicroATX motherboard form factors are backward compatible with standard ATX cases. They use a subset of the ATX mounting holes. You can also use Mini-ITX motherboards in MicroATX cases.
You will need a computer case compatible with your motherboard form factor.
PCIe Expansion Slots
The Z690 and H670 chipsets provide the most flexibility, allowing multiple PCIe 5.0 graphics cards in the dual x8 configuration.
The H610 chipset, on the other hand, is very limited, with only a single PCIe 5.0 x16 slot and no additional PCIe 4.0 slots.
Recommended 13th Gen Motherboards and CPUs
Best Intel 13th Gen High-Performance CPU and Motherboard
- Our recommended Intel 13th gen high-performance enthusiast CPU:
Intel Core i9-13900K Check Price on Amazon Amazon Affiliate Link
- Up to 5.8 GHz max-turbo stock speed: perfect for games, video editing, and high-intensity tasks.
- 24 cores (8 Performance + 16 Efficiency): This combination makes it a great all-around system that can handle any task you throw at it.
- Virtualization features make it great for running virtual machines.
- Check the latest price of the Intel Core i9-13900K on Amazon (affiliate link).
- For the Intel Core i9-13900K CPU, you'll need a motherboard with overclocking support to overclock the CPU. Motherboards with the Z790 chipset typically support CPU overclocking. Otherwise, you can use a motherboard with Intel's other 600-series desktop chipsets (e.g., Z690, H670, B660, H610).
- Our recommended motherboard to pair with the i9-13900K:
MSI MEG Z790 ACE Gaming Motherboard Check Price on Amazon Amazon Affiliate Link
- PCIe 5.0 support
- It supports up to 128 GB of DDR5 memory (DDR5 provides the fastest memory speeds)!
- 2.5 Gbps Ethernet port is faster than any home Internet speed available with tons of room to spare for file transfers.
- Wi-Fi 6E makes it easy to reach the fastest speeds and future-proof your Wi-Fi system.
- Bluetooth 5.3 is great for streaming music to Bluetooth headphones.
- Five x4 NVMe M.2 slots, which is fantastic! One of these supports PCIe 5.0 speeds, and the rest run at PCIe 4.0 speeds.
- USB 3.2 Gen 2x2 offers 20 Gbps USB speeds!
- Check the latest price of the MSI MEG Z790 ACE Gaming Motherboard on Amazon (affiliate link).
Best Runner-Up Intel 13th Gen CPU and Motherboard
- Our recommended Intel 13th gen high-performance CPU:
Intel Core i7-13700K Check Price on Amazon Amazon Affiliate Link
- Up to 5.4 GHz max-turbo stock speed: perfect for games, video editing, and high-intensity tasks.
- 16 cores (8 Performance + 8 Efficiency): This combination makes it a great all-around system that can handle almost any task.
- Virtualization features make it great for running virtual machines.
- Check the latest price of the Intel Core i7-13700K on Amazon (affiliate link).
- For the Intel Core i7-13700K CPU, you'll need a motherboard with overclocking support to overclock the CPU. Motherboards with the Z790 chipset typically support CPU overclocking. Otherwise, you can use a motherboard with Intel's other 600-series desktop chipsets (e.g., Z690, H670, B660, H610).
- Our recommended motherboard to pair with the i7-13700K:
ASUS ROG Strix Z790-E Gaming WiFi 6E Check Price on Amazon Amazon Affiliate Link
- PCIe 5.0 support
- It supports up to 128 GB of DDR5 memory (DDR5 provides the fastest memory speeds)!
- 2.5 Gbps Ethernet port is faster than any home Internet speed available with tons of room to spare for file transfers.
- Wi-Fi 6E makes it easy to reach the fastest speeds and future-proof your Wi-Fi system.
- Bluetooth 5.3 is great for streaming music to Bluetooth headphones.
- Five x4 NVMe M.2 slots, which is fantastic! One of these supports PCIe 5.0 speeds, and the rest run at PCIe 4.0 speeds.
- USB 3.2 Gen 2x2 offers 20 Gbps USB speeds!
- Check the latest price of the ASUS ROG Strix Z790-E Gaming WiFi 6E on Amazon (affiliate link).
Best Value Intel 13th Gen CPU and Motherboard
- Our recommended Intel 13th gen best value CPU:
Intel Core i5-13600K Check Price on Amazon Amazon Affiliate Link
- Up to 5.1 GHz max-turbo stock speed: great for games, video editing, and high-intensity tasks.
- 14 cores (6 Performance + 8 Efficiency): This combination makes it a great all-around system that can handle almost any task.
- Virtualization features make it great for running virtual machines.
- Check the latest price of the Intel Core i5-13600K on Amazon (affiliate link).
- Our recommended Value motherboard to pair with the i5-13600K:
MSI MAG B760 Tomahawk WiFi DDR4 Gaming Motherboard Check Price on Amazon Amazon Affiliate Link
- PCIe 5.0 support
- It supports up to 128 GB of DDR4 memory.
- 2.5 Gbps Ethernet port is faster than any home Internet speed available with tons of room to spare for file transfers.
- Wi-Fi 6E makes it easy to reach the fastest speeds and future-proof your Wi-Fi system.
- Bluetooth 5.3 is great for streaming music to Bluetooth headphones.
- Three x4 NVMe M.2 slots, which is fantastic! These slots all support PCIe 4.0 speeds.
- USB 3.2 Gen 2x2 offers 20 Gbps USB speeds!
- Check the latest price of the MSI MAG B760 Tomahawk WiFi DDR4 on Amazon (affiliate link).
Considerations When Choosing a CPU Cooler
Enermax Liqmax III 360
Check Price on Amazon
Amazon Affiliate Link
Thermal Dissipation
A CPU cooler's TDP (Thermal Design Power) rating indicates how much heat it can dissipate in watts. If the cooler can't keep your CPU cool enough, your CPU may throttle (slow down), and your cooler will constantly run at full speed.
Intel CPU specifications indicate this power dissipation number as "Processor Base Power" and "Maximum Turbo Power."
For example, the Core i9-12900K has a TDP of 125–241 watts, depending on the workload.
A CPU cooler can still work with a lower TDP rating than the TDP of a CPU. However, the CPU will eventually throttle itself to a lower frequency to allow itself to cool.
The CPU may not achieve or maintain maximum turbo speeds without adequate cooling.
Types of Coolers
Air coolers use a combination of heatsinks and fans. They are the cheapest, but also the loudest.
A Closed-Loop Cooler (CLC), also called an All-in-One (AIO) cooler, is a type of liquid cooler. All-in-one liquid coolers provide a more straightforward setup in a single pre-built package.
Liquid cooling can provide even better TDP performance at lower noise levels but are more expensive and take up more room. The noise level and ability to cool your CPU will depend on the liquid cooling solution's radiator size and the number and size of the fans.
Find AIO Coolers on Amazon (affiliate link).
Open-Loop Coolers are also a type of liquid cooler, except you construct them yourself. They allow for more flexibility in building your perfect cooling solution but can also be more complicated to set up. Open-loop systems give you the flexibility to cool additional devices, such as your graphics card's GPU.
Noise
More fans typically mean better cooling. However, they also mean more noise.
Larger fans are typically quieter than smaller fans, as they can move the same amount of air at lower speeds.
If a cooler is struggling to cool a CPU, it will run at its maximum speed, which will be louder.
Fan noise levels are measured a dB. Lower dB values are quieter.
You can often configure your motherboard's BIOS to use specific fan speeds at particular temperatures. This configurable fan speed allows you to have a near-silent computer while your computer is idle.
Mounting Brackets
CPU coolers can have various mounting brackets to work with different socket sizes. Make sure that your cooler comes with a compatible mounting bracket.
The easiest way to find a CPU cooler that will work for your computer is to search by socket type. For example, Intel's 12th generation Core i9 12900K uses an LGA 1700 socket, so you would search for an LGA 1700 CPU cooler. In some cases, such as when a new socket size is released, there may not be many compatible coolers. In these cases, you can often purchase a separate mounting/
Size
Before buying the biggest cooler possible, ensure that your case and motherboard configuration have room.
Also, ensure that other components on your motherboard won't interfere due to size constraints. For example, do your memory modules (DIMMs) have tall heat spreaders?
Dual-fan coolers often take up quite a bit of room. Liquid cooling solutions typically position fans at the top or bottom of the case.
Lighting
Some CPU cooler fans come with LED lighting. Similarly, liquid cooling pump heads can also come with LEDs or even LCDs!
If you want to turn off the lights when they get annoying, make sure your CPU cooler has that option.
Price
In general, air-based coolers will be lower cost than liquid cooling systems.
CPU coolers that support a higher TDP are also typically correlated with a higher price.
The more advanced lighting features tend to also come at an extra cost. You can decide between a practical, low-cost solution and a dazzling light show.
Recommended CPU Cooler for Intel's 13th Gen Core CPUs
Locked Intel CPUs may come with a stock CPU cooler. These CPU models do not have a "K" in the name. While stock coolers will prevent your CPU from overheating, your CPU will throttle its performance during games and other intensive tasks. Higher TDP coolers will keep your CPU at turbo speeds for longer durations. Stock coolers are often quite loud at their maximum speed.
The LGA 1700 socket will require a CPU cooler that supports the new socket size. Some manufacturers are releasing upgrade kits for LGA 1200 heatsinks to support the new size.
Best AIO Liquid Cooler: Enermax Liqmax III 360
- This Enermax liquid cooler has an excellent cooling capability with a 360-watt TDP (Thermal Design Power).
- Supports a variety of CPU sockets, including Intel LGA 2066, 2011-3, 2011, 1700, 1200, 1366, 1156, 1155, 1151, 1150 and AMD AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1.
- Quiet operation at 14-27 dBA.
- You can get the LGA 1700 Enermax Mounting Kit for LIQMAX III on Amazon (affiliate link) or request a free LGA 1700 mounting kit via the LGA 1700 Mounting Kit Request Form.
- Make sure your computer case dimensions support this, as it will take up a decent amount of space!
Enermax Liqmax III 360 Check Price on Amazon Amazon Affiliate Link
Best Dual-Fan Air CPU Cooler: Noctua NH-D15
- Dual 140 mm fans provide 220-watt TDP (183 NSPR) of cooling capability.
- Supports a variety of CPU sockets, including Intel LGA 1700, 1200, 1156, 1155, 1151, 1150, 2011, 2066 and AMD AM4, AM3, AM3+, AM2, AM2+, FM2, FM2+.
- Quiet operation at 24.6 dBA.
Noctua NH-D15, Premium CPU Cooler Check Price on Amazon Amazon Affiliate Link
Runner-Up - Dual-Fan Air CPU Cooler: Thermaltake TOUGHAIR 510
- This CPU cooler doesn't have any fancy LED lights, but the dual 120 mm fans do a great job of cooling LGA 1700 CPUs.
- Suppose you think this cooler will take up too much space. In that case, Thermaltake has a few single-fan TOUGHAIR variants which use different orientations.
- This CPU cooler has a 2000 RPM max speed for optimal cooling.
- 180-watt TDP (Thermal Design Power).
Thermaltake TOUGHAIR 510 Check Price on Amazon Amazon Affiliate Link
Our Recommended RAM
Before purchasing memory, review your motherboard specification to verify which speeds are supported. For example, if a DDR4 motherboard stated that it supports "DDR4 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000," that would mean that it could support DDR4-3400, DDR4-3333, and DDR4-3300 with memory overclocking, and DDR4-3200 and DDR4-3000 at stock speeds. Motherboard specifications also indicate the maximum capacity per stick of RAM (DIMM) and across all slots.
for a specific 13th Gen Core Intel CPU:
Recommended DDR5
- At an effective frequency of 5600 MHz, this memory hits the fastest DDR5 speed supported by Intel's 13th Gen CPUs without overclocking.
Corsair DOMINATOR PLATINUM RGB DDR5 32 GB (2 x 16 GB) 5600 MHz RAM Check Price on Amazon Amazon Affiliate Link
- 32 GB provides ample memory for gaming and multitasking.
- Optimized for Intel XMP 3.0.
Recommended DDR4
- At an effective frequency of 3200 MHz, this memory hits the fastest supported stock DDR4 speeds.
Corsair Vengeance LPX DDR4 Check Price on Amazon Amazon Affiliate Link
- It is also available in other (effective) frequencies for overclockers, including 3600 MHz and 4000 MHz.
- Lower-speed versions are also available on Amazon, in various capacities, including DDR4-2933 (affiliate link), DDR4-2666 (affiliate link), and DDR4-2400 (affiliate link).
- The low-profile form factor ensures that the heat spreaders don't get in the way of other devices, including your CPU heatsink.
Other Considerations When Building a PC
Want to brush up on other new technologies to consider when building a computer? Check out these articles:
- Cases:
- CPUs:
- The Best CPUs for Gaming
- Which Intel and AMD CPUs Support PCIe 5.0?
- Which Intel and AMD CPUs Support PCIe 4.0?
- LGA 1700 CPU List
- LGA 1200 CPU List
- Look up an Intel or AMD CPU on TechReviewer for related recommendations:
- The Best CPUs for Gaming
- CPU Coolers:
- Storage:
- Memory:
- PCI-Express:
- Motherboards:
- Graphics Cards:
- Power Supplies:
- Keyboards:
- Monitors:
A Note From the Authors
As technology experts, we are dedicated to providing accurate and helpful information on various technology products and services. Our goal is to provide valuable insights and recommendations that help our readers make informed decisions.
We understand that the technology industry is constantly evolving, and we strive to stay up-to-date with the latest trends and developments. However, we recognize that there may be occasions when errors or inaccuracies slip through, despite our best efforts.
That's why we welcome feedback from our readers and encourage them to reach out to us with any corrections or suggestions they may have. By working together, we can ensure that our content remains accurate, helpful, and up-to-date.
If you have any feedback or suggestions for us, please don't hesitate to get in touch. We value your input and look forward to hearing from you.
