Which Motherboard Should You Buy for Intel's 12th Gen CPUs?

Best Feature Motherboard

GIGABYTE Z690 AORUS Master Check Price on Amazon Amazon Affiliate Link

Best Value Motherboard

GIGABYTE Z690 AORUS Elite AX DDR4 Check Price on Amazon Amazon Affiliate Link

Motherboard Requirements for Intel's 12th Generation Core CPUs

Motherboards for Intel processors are made with chipsets provided by Intel. Each chipset offers a unique set of capabilities. However, motherboards must explicitly support features and capabilities for you to use them. Verify that a motherboard supports the features and capabilities you desire.

For 12th Gen Intel Core processors, you'll need a motherboard with an LGA 1700 socket and a 600-series or 700-series chipset. Intel's 700-series chipsets were primarily designed for 13th generation Core processors but are backward compatible with all 12th generation Core processors.

You will need a motherboard with overclocking support to overclock 12th Gen CPUs. Motherboards with the Z790 and Z690 chipsets typically support CPU overclocking. Otherwise, you can use a motherboard with Intel's other 700-series or 600-series desktop chipsets (e.g., H770, B760, H670, B660, H610).

The W680 and Q670 chipsets are intended for workstation and business use cases; their availability in stand-alone motherboards is limited.

• Find Z790 Chipset Motherboards on Amazon (affiliate link).

• Find H770 Chipset Motherboards on Amazon (affiliate link).

• Find B760 Chipset Motherboards on Amazon (affiliate link).

• Find Z690 Chipset Motherboards on Amazon (affiliate link).

• Find H670 Chipset Motherboards on Amazon (affiliate link).

• Find B660 Chipset Motherboards on Amazon (affiliate link).

• Find H610 Chipset Motherboards on Amazon (affiliate link).

Featured Intel 12th Gen Motherboards › Amazon Affiliate Links MSI PRO Z690-A DDR4 ProSeries Motherboard (ATX, 12th Gen Intel Core, LGA 1700 Socket, DDR4, PCIe 4, CFX, M.2 Slots) Check Price on Amazon ASUS ROG Strix Z690-E Gaming WiFi 6E LGA 1700(Intel 12th Gen)ATX gaming motherboard(PCIe 5.0,DDR5,2.5 Gb LAN,Thunderbolt 4,5xM.2,1xPCIe 5.0 M.2,ROG Hyper M.2 Card,Front panel USB 3.2 Gen 2x2 Type-C) Check Price on Amazon

DDR4 or DDR5 Memory

Because DDR4 and DDR5 are not backward compatible, you must decide which one you want to go with before selecting a motherboard.

DDR5 memory is currently more expensive than DDR4.

However, it offers up to double the stock data rates of DDR4. Overclockers could push this limit even further.

Additionally, DDR5 supports higher-capacity DIMMs (256 GB vs. 64 GB).

DDR5 may experience slower timings at initial release but should be much better than DDR4 as the technology matures. However, keep in mind that the timings scale inversely with the clock rate (frequency). The timing values are in units of clock cycles, but more cycles are happening per second with DDR5. For example, DDR3-2133 CL10 has nearly the same latency as DDR5-8400 CL40. So don't let the CL40 latency of DDR5 scare you away; the number just looks bigger!

GIGABYTE Z690 AORUS Master

Other Considerations When Choosing a 12th Gen Motherboard

In addition to selecting a motherboard with an LGA 1700 socket type and compatible chipset, here are a few other things to consider when picking a motherboard. Some of these considerations will help determine the best chipset to use.

To be able to overclock DDR memory, such as via an XMP profile, your motherboard chipset needs to support memory overclocking.

An "F" in the CPU's model name indicates that the CPU does not have integrated graphics support and requires a separate graphics card. Because it doesn't have integrated graphics support, you won't need a motherboard with a video output port (e.g., HDMI).

The lack of an "F" in the model name indicates that the CPU has integrated graphics support. You will need to make sure that your motherboard also has a video output port (e.g., HDMI) if you want to use the integrated graphics.

Even if you primarily connect your monitors to a graphics card, integrated graphics can be beneficial when troubleshooting and fixing graphics card problems.

NVMe M.2 cards are the latest and fastest form of SSD storage. However, you need to ensure that your motherboard includes enough slots.

The Z790, H770, Z690, and H670 chipsets support the most PCIe 4.0 lanes, which means that motherboards with these chipsets are likely to have the most x4 NVMe M.2 slots available.

Learn more about storage types in my article Storage Type Comparison: M.2, U.2, NVMe, SATA, SSDs, HDDs.

Make sure that the motherboard provides enough USB ports at your desired speeds. The Z690 and Z790 can support the most USB ports at USB 3.2 2x2 (20 Gbps), USB 3.2 2x1 (10 Gbps), and USB 3.2 1x1 (5 Gbps) speeds.

The devices that are likely to need the high bandwidth rates will typically be limited to storage devices and high-resolution video devices.

Make sure that the motherboard has your desired audio outputs.

For example, if you have a surround sound system, ensure that it comes with rear and center speaker ports.

If your audio equipment requires an optical input, consider getting a motherboard with this port.

Alternatively, you can purchase a separate PCIe or USB sound card to add additional port types such as optical or RCA.

When it comes to motherboards, we've come across three main form factors. In our experience, ATX stands out as the most common form factor for desktop PCs. We've also tried and analyzed the Mini-ITX and MicroATX form factors for building a mini-PC. We have found that these smaller form factors typically have fewer PCIe card slots, fewer RAM slots, and can't support as many storage devices.

We've seen that these smaller Mini-ITX and MicroATX motherboard form factors are backward compatible with standard ATX cases. We observed that they use a subset of the ATX mounting holes. In fact, we've used Mini-ITX motherboards in ATX cases many times.

One crucial consideration is ensuring that your computer case is compatible with your specific motherboard form factor. We learned this through our own experiences and it's important to choose a case that matches your motherboard form factor.

The Z690 and H670 chipsets provide the most flexibility, allowing multiple PCIe 5.0 graphics cards in the dual x8 configuration.

The H610 chipset, on the other hand, is very limited, with only a single PCIe 5.0 x16 slot and no additional PCIe 4.0 slots.

Recommended 12th Gen Motherboards and CPUs

• Our recommended Intel 12th gen high-performance enthusiast CPU: Intel Core i9-12900K Processor 16 Cores (8P+8E) up to 5.2 GHz Check Price on Amazon Amazon Affiliate Link
  • Up to 5.2 GHz: perfect for games, video editing, and high-intensity tasks.
  • 16 cores (8 Performance + 8 Efficiency): Quite a few cores considering the frequency! This combination makes it a great all-around system that can handle almost any task.
  • Virtualization features make it great for running virtual machines.
  • Check the latest price of the Intel Core i9-12900K on Amazon (affiliate link).
  • For the Intel Core i9-12900K CPU, you'll need a motherboard with overclocking support to overclock the CPU. Motherboards with the Z690 chipset typically support CPU overclocking. Otherwise, you can use a motherboard with Intel's other 600-series desktop chipsets (e.g., H670, B660, H610).
• Our recommended motherboard to pair with the i9-12900K: GIGABYTE Z690 AORUS Master Check Price on Amazon Amazon Affiliate Link
  • PCIe 5.0 support
  • It supports up to 128 GB of DDR5 memory (DDR5 provides the fastest memory speeds)!
  • 10 Gbps Ethernet port is faster than any home Internet speed available with tons of room to spare for file transfers.
  • Wi-Fi 6E makes it easy to reach the fastest speeds and future-proof your Wi-Fi system.
  • Bluetooth 5.2 is great for streaming music to Bluetooth headphones.
  • Four x4 NVMe M.2 slots, which is fantastic! Three of these run at PCIe 4.0 speeds, and one at PCIe 3.0 speeds.
  • USB 3.2 Gen 2x2 offers 20 Gbps USB speeds!
  • Check the latest price of the GIGABYTE Z690 AORUS Master on Amazon (affiliate link).

• Our recommended Intel 12th gen value CPU: Intel Core i5-12600K Check Price on Amazon Amazon Affiliate Link
  • Less than half the price of the i9-12900K, but still excellent performance at up to 4.9 GHz.
  • 10 cores (6 Performance + 4 Efficiency): This core count makes it suitable for everyday multi-threading tasks, such as having tons of browser windows open.
  • Virtualization features make it great for running virtual machines.
  • Check the latest price of the Intel Core i5-12600K on Amazon (affiliate link).
  • For the Intel Core i5-12600K CPU, you'll need a motherboard with overclocking support to overclock the CPU. Motherboards with the Z690 chipset typically support CPU overclocking. Otherwise, you can use a motherboard with Intel's other 600-series desktop chipsets (e.g., H670, B660, H610).
• Our recommended motherboard to pair with the i5-12600K: GIGABYTE Z690 AORUS PRO Check Price on Amazon Amazon Affiliate Link
  • PCIe 5.0 support
  • It supports up to 128 GB of DDR5 memory!
  • Three NVMe M.2 slots, which is excellent! These all run at PCIe 4.0 speeds.
  • 2.5 Gb Ethernet port is faster than most home Internet speeds with room to spare for file transfers.
  • USB 3.2 Gen 2x2 offers 20 Gbps USB speeds!
  • Check the latest price of the GIGABYTE Z690 AORUS PRO on Amazon (affiliate link).

Considerations When Choosing a CPU Cooler

A CPU cooler's TDP (Thermal Design Power) rating indicates how much heat it can dissipate in watts. If the cooler can't keep your CPU cool enough, your CPU may throttle (slow down), and your cooler will constantly run at full speed.

Intel CPU specifications indicate this power dissipation number as "Processor Base Power" and "Maximum Turbo Power."

For example, the Core i9-12900K has a TDP of 125–241 watts, depending on the workload.

A CPU cooler can still work with a lower TDP rating than the TDP of a CPU. However, the CPU will eventually throttle itself to a lower frequency to allow itself to cool.

The CPU may not achieve or maintain maximum turbo speeds without adequate cooling.

Air coolers use a combination of heatsinks and fans. They are the cheapest, but also the loudest.

A Closed-Loop Cooler (CLC), also called an All-in-One (AIO) cooler, is a type of liquid cooler. All-in-one liquid coolers provide a more straightforward setup in a single pre-built package.

Liquid cooling can provide even better TDP performance at lower noise levels but are more expensive and take up more room. The noise level and ability to cool your CPU will depend on the liquid cooling solution's radiator size and the number and size of the fans.

Find AIO Coolers on Amazon (affiliate link).

Open-Loop Coolers are also a type of liquid cooler, except you construct them yourself. They allow for more flexibility in building your perfect cooling solution but can also be more complicated to set up. Open-loop systems give you the flexibility to cool additional devices, such as your graphics card's GPU.

More fans typically mean better cooling. However, they also mean more noise.

Larger fans are typically quieter than smaller fans, as they can move the same amount of air at lower speeds.

If a cooler is struggling to cool a CPU, it will run at its maximum speed, which will be louder.

Fan noise levels are measured a dB. Lower dB values are quieter.

You can often configure your motherboard's BIOS to use specific fan speeds at particular temperatures. This configurable fan speed allows you to have a near-silent computer while your computer is idle.

CPU coolers can have various mounting brackets to work with different socket sizes. Make sure that your cooler comes with a compatible mounting bracket.

The easiest way to find a CPU cooler that will work for your computer is to search by socket type. For example, Intel's 12th generation Core i9 12900K uses an LGA 1700 socket, so you would search for an LGA 1700 CPU cooler. In some cases, such as when a new socket size is released, there may not be many compatible coolers. In these cases, you can often purchase a separate mounting/retention kit to work with the new dimensions.

Before buying the biggest cooler possible, ensure that your case and motherboard configuration have room.

Also, ensure that other components on your motherboard won't interfere due to size constraints. For example, do your memory modules (DIMMs) have tall heat spreaders?

Dual-fan coolers often take up quite a bit of room. Liquid cooling solutions typically position fans at the top or bottom of the case.

Some CPU cooler fans come with LED lighting. Similarly, liquid cooling pump heads can also come with LEDs or even LCDs!

If you want to turn off the lights when they get annoying, make sure your CPU cooler has that option.

In general, air-based coolers will be lower cost than liquid cooling systems.

CPU coolers that support a higher TDP are also typically correlated with a higher price.

The more advanced lighting features tend to also come at an extra cost. You can decide between a practical, low-cost solution and a dazzling light show.

Recommended CPU Cooler for Intel's 12th Gen Core CPUs

Locked Intel CPUs are typically bundled with a stock CPU cooler and are identifiable by the absence of the "K" in their model name. While these coolers are adequate for preventing the CPU from overheating, they may limit the processor's performance during demanding tasks such as gaming. Additionally, stock coolers may produce noticeable noise when running at maximum speed.

A higher TDP cooler is recommended to sustain the peak speeds for extended periods to ensure optimal performance.

A CPU cooler that is compatible with the LGA 1700 socket will be required. Several manufacturers introduced upgrade kits to accommodate the LGA 1700 socket size that allows LGA 1200 coolers to be used. So be sure to verify that any cooler you choose is compatible with your CPU.

• TechReviewer

• I was very impressed with the cooling capability of the Enermax Liqmax III 360, which boasts an excellent 360-watt TDP (Thermal Design Power).

• Supports a variety of CPU sockets, including Intel LGA 2066, 2011-3, 2011, 1700, 1200, 1366, 1156, 1155, 1151, 1150 and AMD AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1.

• I found that the Enermax Liqmax III 360 operates quietly and unobtrusively, with a noise level of just 14-27 dBA, making it a great choice for anyone who values a quiet computing environment.

• You can get the LGA 1700 Enermax Mounting Kit for LIQMAX III on Amazon (affiliate link) or request a free LGA 1700 mounting kit via the LGA 1700 Mounting Kit Request Form.

• If you are considering the Enermax Liqmax III 360, it's important to note that it will take up a decent amount of space in your computer case, so make sure to check the dimensions before purchasing.

• The Enermax Liqmax III 360 has an impressive cooling capacity, providing efficient heat dissipation even under heavy workloads.

• The quiet operation of the cooler made for a more comfortable and distraction-free computing experience. Enermax Liqmax III 360 Check Price on Amazon Amazon Affiliate Link

• TechReviewer

• I found the dual 140 mm fans to be incredibly powerful, providing an impressive 220-watt TDP (183 NSPR) of cooling capability.

• With support for such a diverse range of CPU sockets, I found the Noctua NH-D15 to be a very flexible and adaptable cooling solution. Its supported socket types include Intel LGA 1700, 1200, 1156, 1155, 1151, 1150, 2011, 2066 and AMD AM4, AM3, AM3+, AM2, AM2+, FM2, FM2+.

• In my experience, the Noctua NH-D15 operates very quietly, with a noise level of just 24.6 dBA.

• I am extremely satisfied with the Noctua NH-D15 cooler and would highly recommend it to anyone who is looking for a high-performance and versatile cooling solution. Noctua NH-D15, Premium CPU Cooler Check Price on Amazon Amazon Affiliate Link

• TechReviewer

• As someone who isn't a big fan of flashy LED lights, I appreciated the simplicity of the Thermaltake TOUGHAIR 510, which doesn't have any fancy lights but still looks great in my system.

• I found that the dual 120 mm fans on the TOUGHAIR 510 did an excellent job of keeping an LGA 1700 CPU cool, even under heavy workloads.

• If you're worried about the TOUGHAIR 510 taking up too much space in your system, Thermaltake offers a few single-fan variants that use different orientations, so you can choose the one that works best for your setup.

• With a max speed of 2000 RPM, the TOUGHAIR 510 provides optimal cooling performance when you need it most.

• With a 180-watt TDP (Thermal Design Power), the TOUGHAIR 510 offers solid cooling performance and is a great choice for anyone looking for a reliable and efficient cooling solution for their CPU. Thermaltake TOUGHAIR 510 Check Price on Amazon Amazon Affiliate Link

Our Recommended RAM

Before purchasing memory, we suggest that you review your motherboard specification to verify which speeds are supported. For example, if a DDR4 motherboard stated that it supports "DDR4 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000," that would mean that it could support DDR4-3400, DDR4-3333, and DDR4-3300 with memory overclocking, and DDR4-3200 and DDR4-3000 at stock speeds. We have seen that motherboard specifications also indicate the maximum capacity per stick of RAM (DIMM) and across all slots.

• At an effective frequency of 5600 MHz, this memory hits the fastest DDR5 speed supported by Intel's 13th Gen CPUs without overclocking. Corsair DOMINATOR PLATINUM RGB DDR5 32 GB (2 x 16 GB) 5600 MHz RAM Check Price on Amazon Amazon Affiliate Link
• 32 GB provides ample memory for gaming and multitasking.
• Optimized for Intel XMP 3.0.

• At an effective frequency of 3200 MHz, this memory hits the fastest supported stock DDR4 speeds. Corsair Vengeance LPX DDR4 Check Price on Amazon Amazon Affiliate Link
• It is also available in other (effective) frequencies for overclockers, including 3600 MHz and 4000 MHz.
• Lower-speed versions are also available on Amazon, in various capacities, including DDR4-2933 (affiliate link), DDR4-2666 (affiliate link), and DDR4-2400 (affiliate link).
• The low-profile form factor ensures that the heat spreaders don't get in the way of other devices, including your CPU heatsink.
