Choosing the Best PSU for AMD's Radeon RX 480 GPU

Learn about what to look for when choosing a power supply for AMD's Radeon RX 480 GPU.

PC Power Supply

Last Updated: September 6, 2022

Written by Kevin Jones

In this article, I'll go over the things you should consider when choosing a power supply for your computer with an AMD Radeon RX 480 graphics card.

Check out my Recommended Power Supplies for RX 480 GPUs below.

How to Choose a Power Supply for the RX 480 GPU

Section Link

The main job of a power supply is to convert the alternating current (AC) from your wall outlet into the direct current (DC) needed by the components inside your computer.

Power Output

An important factor when buying a PSU is the supported wattage.

You can estimate your power needs by using the following chart.

Component Peak Power Usage
RX 480 GPU 150 W
Top-Tier CPU (e.g., Intel Core i9 12900K) 241 W
Mid-Tier CPU (e.g., Intel Core i5 12600K) 150 W
Motherboard 80 W
Optical Drive 30 W
3.5" Hard Drive 9 W
M.2 or 2.5" SSD 9 W
140 mm Case/CPU Fan 6 W
120 mm Case/CPU Fan 6 W
80 mm Case/CPU Fan 3 W

By adding up these numbers, you can estimate peak power usage. Check out the top-tier and mid-tier example builds below.

It's generally a good idea to add a 100–150 W buffer to your expected usage. This buffer will give you some flexibility in case of miscalculations and will allow you to add more drives, fans, or add-in cards in the future.

In most cases, buying a little more wattage than you need is a safer choice for ensuring system stability.

Don't forget to account for the additional power required for overclocking if you intend to overclock your CPU or GPU. Overclocking could require roughly an extra 50–100 W, depending on how much you overclock these devices.

Check another AMD GPU:

Top-Tier Estimate:

Top-Tier Components Peak Power Consumption
RX 480 GPU 150 watts
Top-Tier CPU (e.g., Intel Core i9 12900K) 241 watts
Motherboard 80 watts
4 M.2 or 2.5" SSDs 36 watts
3 Case Fans (120 mm) 18 watts
2 CPU Fans (120 mm) 12 watts
Total Estimate: 537 watts
Recommended Power Supply Wattage: 700 watts

Check the latest price of the 450–750 watt Corsair SF Power Supplies on Amazon (affiliate link).

Check out my Recommended Power Supplies for RX 480 GPUs below.

Mid-Tier Estimate:

Mid-Tier Components Peak Power Consumption
RX 480 GPU 150 watts
Mid-Tier CPU (e.g., Intel Core i5 12600K) 150 watts
Motherboard 80 watts
2 M.2 or 2.5" SSDs 18 watts
2 Case Fans (120 mm) 12 watts
2 CPU Fans (120 mm) 12 watts
Total Estimate: 422 watts
Recommended Power Supply Wattage: 550 watts

Check the latest price of the 450–750 watt Corsair SF Power Supplies on Amazon (affiliate link).

Check out my Recommended Power Supplies for RX 480 GPUs below.

Power Efficiency

PSUs with higher efficiency ratings use less energy and produce less heat, improving their reliability and reducing noise.

The 80 PLUS certification program for power supplies helps to promote energy efficiency by indicating its efficiency rating.

Higher efficiency power supplies may have a higher upfront cost. However, they could potentially save you money on electricity in the long run.

Lower wattage PSUs will be more power-efficient even when idle. For this reason, you may be able to save more on electricity by getting the correct wattage of PSU than by getting the one with the best 80 PLUS rating.

PSU Efficiency Levels (115 V)
Certification Level10% Load20% Load50% Load100% Load
80 Plus 80% 80% 80%
80 Plus Bronze 82% 85% 82%
80 Plus Silver 85% 88% 85%
80 Plus Gold 87% 90% 87%
80 Plus Platinum 90% 92% 89%
80 Plus Titanium 90% 92% 94% 90%

Cables

Connectors

Make sure your PSU has the correct connectors to support the hardware in your system. Cheaper PSUs may cut costs on connectors and cables by offering fewer options and shorter lengths.

Check with your motherboard and graphics card documentation to determine which connector types are needed. Buy a popular, recently-released PSU; it will likely have the necessary connectors for a new PC build. However, if you use old components or an old power supply, you may find some incompatibilities.

Here are some common connector types that power supplies support:

  • 24-pin connector for the motherboard
  • 4/8-pin connector for the CPU
  • 6/8-pin connectors for graphics cards
  • SATA Power connector for each SATA HDD or SDD storage device

The latest graphics cards and PSUs are starting to support a new 16-pin PCIe 5.0 connector that replaces multiple 8-pin connectors.

Modular Cables

Typical power supplies come with various cables to connect your components. However, extra unused power cables can work against you by interrupting airflow.

In comparison, modular and semi-modular power supplies allow for attaching only the cables you need. As the name implies, semi-modular power supplies have some wires soldered on, while you can optionally connect others.

Cable Lengths

Most power supplies will have cables long enough to support mid-sized towers comfortably. If you have a full-size tower, you may want to check reviews and documentation to ensure that the cables are long enough to allow good cable management.

Power Supply Form Factors

Various form factors are available for power supplies. However, a standard-size desktop PC build will use an ATX power supply.

Small form factor PSUs allow for usage in many computer case shapes, including mini-PCs.

Power Supply Features

Overvoltage protection and short circuit protection can help to save your components in the case of a surge or accident.

LED lighting is another feature you might consider, depending on your PC goals.

Choosing a Cost-Effective Power Supply for the RX 480

Section Link

Perhaps you live in a dorm or a family member's house and don't pay the power bill. Or maybe you don't expect the computer to have heavy daily usage. In those cases, the lower upfront cost of a less efficient PSU may be the better choice.

On the other hand, if you care more about the electric bill or the environment and plan to maintain higher CPU or GPU usage, then a more efficient PSU may be better.

Don't go too far over 150 W above your expected power needs. Rightsizing your power supply will keep electricity costs to a minimum, as higher wattage PSUs will consume some additional power, even when idle.

Section Link
  • Titanium 80 PLUS efficiency rating means the Seasonic Prime TX is at least 94% efficient at 50% load.
  • Fully modular cabling allows you to optimize airflow and minimize clutter.
  • Silent during low usage.
  • 12-year warranty.
  • This series of power supplies comes in power outputs including 750, 850, and 1000 watts.
  • It also is available in a Gold rated (GX) version. Seasonic Prime TX-750 Seasonic Prime TX-750 Check Price on Amazon Amazon Affiliate Link
